AT070TN94 基本參數制造商(Productor)產品型號(MODEL)屏尺寸(Size)分辨率(Resolution)分辨率簡稱(Resolution Name)顯示比例(Display scale)像素排列(Pixel Arrangement)點距(Pixel Pitch)產品組成(Panel Composition)面板類型(Technology)主要用途(Applications)顯著特征(Panel Features)AT070TN94光電參數顯示模式(Display mode)亮度(Luminance)對比度(Contrast Ratio)顏色(Color)色彩飽和度(Color Saturation)響應時間(Response)可視角度(Viewing Angle)最佳視角(The Best View)白場色度(White Field Chroma)白場變動(White Field Dynamic)反轉掃描(Reverse Scan)信號類型大類(The kind of Singnal)接口類型(Interface)信號接口定義(Singnal Interface Definition)驅屏電壓(Drive-screen voltage)面板輸入電流(Input Current)信號接口類型(Kind of Singnal Interface)信號接口品牌(Brand of Singnal Interface)信號接口腳距(Pitch of Singnal Interface)信號接口數量(Quantity of Singnal Interface)信號接口腳數(Pin of Singnal Interface)AT070TN94結構參數工作溫度(Operation Temperature)存儲溫度(Storage Temperature)表面處理(Surface Technology)顯示區域(Active Area)可視區域(Display Area)外形尺寸(Outline)觸摸屏(Touch Panel)燈管位置(Lamp Position)背光類型(Backlight)燈管數量(Lamp Number)燈管形狀(Lamp Shape)背光壽命(Life Time of Lamp)單一燈管電壓(Voltage of Lamp)單一燈管電流(Current of Lamp)內置燈管驅動器(Driver of Backlight)背光接口類型(Kind of Backlight Interface)背光接口品牌(Brand of Backlight Interface)背光接口數量(Quantity of Backlight Interface)背光接口腳距(Pitch of Backlight Interface)背光接口定義(Backlight Interface Define )AT070TN94包裝及生產狀態每箱數量(Quantity Per Box)包裝箱尺寸(Size of the Box)包裝箱毛重(G.W. of the Box)開始量產時間(Date Begin Producing)當前生產狀態(Production Status)
| 群創/Innolux |
| AT070TN94 |
| 7.0" |
| 800×480 |
| WVGA |
| 16:9 |
| RGB垂直條狀 |
| 0.0642×0.1790 mm |
| 液晶屏, |
| a-Si TFT-LCD |
| 【便攜式DVD】, 【車載顯示】, |
| 【灰階可選】, 【白光LED】, 【翻轉顯示】, 【霧面】, 【寬溫】, |
| TN，常白顯示，透射式 |
| 400 nits |
| 500:1 |
| 262K/16.7M |
| 50%NTSC(CIE1931) |
| 10/15 (Tr/Td) ms |
| 50/70/70/70(上/下/左/右) |
| 6 o'clock |
| X:0.310; Y:0.330 |
| 1.33 (9 points) |
| 翻轉 (水平/垂直) |
| Parallel |
| Parallel |
| DRGB-50P1C8B-115A |
| 3.3/10.4/16.0/-7.0V (VCC/AVDD/AVDD/VGL) |
| 4/2/0.2/0.2mA (ICC/IAVDD/IGH/IGL) |
| 包含在屏信號接口中 |
| FPC |
| 0.5 mm |
| 1 pcs |
| 50 pins |
| -30 °C ~ 85 °C |
| -30°C ~ 85°C |
| 霧面 |
| 154.08×85.92 mm |
| 156.7×89.1 |
| 164.90× 100.00×5.70 mm |
| 無 |
| 側入式光源 |
| WLED |
| 3S9P pcs |
| 陣列 |
| 20K Hours |
| 9.3V |
| 180mA |
| 無 |
| 包含在屏信號接口中 |
| Includedinsignalinterface |
| 1 pcs |
| 0.5 mm mm |
| DRGB-50P1C8B-115A |
| 50 pcs |
| 530×355×255 mm (長×寬×高) |
| 10.682 Kg |
|
